DP

HYDRAULIC CONE CRUSHER

Raw Material: Iron ore, copper, steel slag, slag, river stone, granite, basalt, quartz stone, diabase

Capacities up to 600 tph

High productivity, low maintenance with the latest cone crusher technology

Infinite adjustment under load

Constant main shaft alignment

Enhanced tramp iron relief

Leave Message

Send E-mail contact@dscrusher.com

OVERALL PROPERTIES technical specification PHOTO/VIDEOS CONTACT US

OVERALL PROPERTIES

DSMAC DP series single cylinder hydraulic cone crusher is of advanced design with a small footprint and high capacity in relation to size. It is ideal for secondary and tertiary crushing stage and the compact and easy-to-service design makes it a perfect choice for mobile installation. DP series hydraulic cone crusher can provide automatic overload protection and can be equipped with automatic setting system.

It is ideal for secondary and tertiary crushing stage in metal mine, quarry, concrete batching station and glass industry etc. Several standard crushing chambers are available for each model. DP series hydraulic cone crusher can easily be matched to change in production by the selection of crushing chamber and eccentric throw.

Model	Cavity type	Max feed (mm)	Outlet(mm)(CSS) & Capacity(t/h)										Weight （kg）
Model	Cavity type	Max feed (mm)	8(mm)	10(mm)	13(mm)	16(mm)	19(mm)	22(mm)	25(mm)	32(mm)	38(mm)	44(mm)	Weight （kg）
DP 440	EC	215				114-200	122-276	131-294	139-313	159-357	175-395	191-384	14300
	C	175			101	109-218	117-292	125-312	133-332	151-378	167-335	183-229
	MC	140			97-122	105-262	113-282	120-301	128-320	146-328	161-242
	M	110			117-187	126-278	136-298	145-318	154-339	175-281	194
	MF	85		114	124-227	134-245	144-263	153-281	163-299	186-248
	F	70	90-135	96-176	104-191	112-206	120-221	129-236	137-251	156-208
	EF	38	100-125 80%＜6mm-7.5mm
DP 660			13	16	19	22	25	32	38	44	51
	EC	275		117	190-338	203-436	216-464	246-547	272-605	298-662	328-511		26800
	CX	245		174-194	187-374	200-488	212-519	242-592	268-654	293-521	323-359
	C	215		171-190	184-367	196-480	209-510	238-582	263-643	288-512	317-353
	MC	175		162-253	174-426	186-455	198-484	226-552	249-499	273-364
	M	135		197-295	211-440	226-470	240-500	274-502	302-403
	MF	115	192	207-369	222-396	237-432	252-460	287-461	318-363
	F	85	195-304	210-328	225-352	241-376	256-400	292-401	323
	EF	65	211-293	227-316	244-298	261-290
DP 440S			25	29	32	35	38	41	44	48	51	54
	EC	450				267	282-353	298-446	313-563	334-601	390-524	356-456	19300
	C	400		225	239-299	254-381	269-484	264-511	298-448	318-398	333
	MC	300	195	214-267	228-342		256-461	270-486	284-426	303-378	317
