Capacity
100-800t/h

Max feeding size
1000mm

Primary and secondary crushing

AF

EUROPEAN IMPACT CRUSHER

Raw material: Granite, basalt, limestone, shale, river stone, cement clinker, quartz stone, phosphate ore, bauxite, slag

Optimized chamber design, high throughput and reduction rate

Option of sensing and feedback system avoids overload due to blockage

Large inlet opening, high throughput rate, premium product shape

Signature chrome white iron blow bar elongates hammer service life

Leave Message

Send E-mail contact@dscrusher.com

Overall Properties Technical Specifications PHOTO/VIDEOS CONTACT US

Overall Properties

Dingsheng® AF series European impact crushers (AF series horizontal shaft impact crushers) offer the most optimized outperforming design for highest reduction ratio and productivity. The compact construction utilizes a special wear resistant alloy steel for key components in the impactor assuring the reliability and safely at all time.

European impact crusher is mainly for primary and secondary crushing applications in mining, aggregates, mineral processing, and recycling construction waste, widely used in metallurgy, mine, cement, chemical engineering, fire resistant materials, ceramics and other industrial sectors, as well as in the expressway construction, water conservancy project, building crushed stone, and machine-made sand process fields, etc.

Model	Max. feed size (mm)	Capacity (t/h)	Power (kw)	Weight (t)
AF270	250×250×500	100-200	160-200	12.5
AF340	250×250×500	150-250	220-250	13.4
AF380	300×300×600	200-300	250-280	15.5
AF430	300×300×600	250-350	280-315	17.4
AF540	400×400×700	300-400	355	34.8
AF540	400×400×700	300-400	400	36.5
AF610	400×400×700	380-500	400	38.5
AF610	400×400×700	380-500	450	41
