Capacity
30-1080 t/h

Max feeding size
400-1600 mm

Long distance transportation

B

BELT CONVEYOR

Stone production line, mining, building materials, metallurgy, chemical industry

Suitable for long distance transportation with larger capacity, continuous delivery.

Small running resistance, rare wear, low power consumption and high production efficiency.

Conveying routine is well-adapted and flexible, free from installation restrictions.

Simple structure, easy maintenance, low cost, strong universality.

Leave Message

Send E-mail contact@dscrusher.com

Overall Properties Technical Specifications PHOTO/VIDEOS CONTACT US

Overall Properties

The B series belt conveyor is a kind of machine that to transfer the material continuously. The belt works under the effect of frictional force. It is not only the components to transfer the material, but also the components to transfer the force.

The B series belt conveyor is advanced and simple in structure, easy to maintain. Its has the features of high transfer capacity and long transfer distance. They are widely used in mining, metallurgical and coal industry to transfer sandy or bulk material, or packaging material. In many situation, it is a very important component of non-standard machinery.

Model	Belt width (mm)	Belt length (m)/Power (kw)			Belt speed (m/s)	Capacity (t/h)
B400	400	≤12/2.2	12-20/2.2-4	20-25/3.5-7.5	1.25-2.0	30-60
B500	500	≤12/3	12-20/3-5.5	20-30/5.5-7.5		40-80
B650	650	≤12/4	12-20/4-5.5	20-30/5.5-11		80-120
B800	800	≤10/4	10-15/4-5.5	15-30/5.5-15		120-200
B1000	1000	≤10/5.5	10-20/5.5-11	20-40/11-22		200-320
B1200	1200	≤10/7.5	10-20/7.5-15	20-40/15-30		290-480
B1400	1400	≤10/11	10-20/11-22	20-40/22-45		400-680
B1600	1600	≤10/15	10-20/22-30	20-50/30-75		600-1080
