WJ
MOBILE JAW CRUSHER

MOBILE JAW CRUSHER
Capacity
100-300 t/h
Max. feed size
600mm
Primary crushing application
Overall Properties
Raw materials: granite, limestone, basalt, shale, river pebble, bluestone, sandstone, calcium carbide, iron ore, copper ore, steel slag, etc.
Applications: primary crushing application in mining, aggregates, mineral processing, and recycling construction and demolition waste.

The WJ series mobile jaw crusher integrates crushing and screening two parts, including feeding system, crushing system, screening system and belt conveying system, adopting integrated group operation as well as separating working method, which eliminates the complex site infrastructure of single machine and auxiliary facilities’ installing operation, and reduces labor consumption.

Feature
1. Compact and sturdy chassis enhances the stability of the production process;
2. Standard advanced intelligence system;
3. Boosted capacity thanks to our Austrian technology JC series jaw crusher;
4. Hybrid power of diesel or electric engine;
5. Independent pre-screening unit option;
6. High mobility and , no infrastructure needed in advance.

Model Max. feed size
(mm)
Capacity
(t/h)
Installed power
(kw)
Generator set
(kw)

Working dimensions
(mm)
Delivering Dimension
(mm)
WJ270 ≤500 100-200 94.3 150 17200 x 4250 x 4400 17200 x 2500 x 4000
WJ380 ≤600 200-300 182.4 300 19400 x 4550 x 4975 17200 x 2800 x 4400
