TAFS
TRACKED CRUSHING AND SCREENING PLANT

TRACKED CRUSHING AND SCREENING PLANT
Capacity
100-300 t/h
Max. feed size
500mm
Integrated modular design
Overall Properties
Raw materials:  granite, limestone, basalt, shale, pebbles, ore, steel slag, quartz, silica, gypsum, volcanic rock, marble, river stone, calcite, dolomite, coal gangue, tiles, concrete hollow blocks, cement clinker etc..
Application: minerals and hard rock crushing, construction waste recycling, slag processing, highway and tunnel construction, water conservancy, metallurgy, chemical industry etc.

The TAFS series tracked crushing and screening plant is an integration of new type energy-saving, efficient crusher in the international advanced level. Modular design, excellent combination, intelligent wireless operation, low cost and efficient operation. We put the site design, environmental protection, easy to transport, and saving energy as the primary problem to be resolved, providing customers with the best technology of crushing solution.

With high performance, high reliability and attractive appearance, the tracked crushing and screening plant has reached the international advanced level. We can design the primary crushing, secondary crushing, tertiary crushing and combine them according to customers' requirement.

Model Max. feed size
(mm)
Capacity
(t/h)
Installed power
(kw)
Running power
(kw)
Working dimension
(mm)
Delivering dimension
(mm)
TAFS270 ≤400 100-200 281 75 15400 x 10400 x 7200 15600 x 3300 x 4000
TAFS380 ≤500 200-300 365 90 18330 x 10400 x 7200 18400 x 3400 x 4000
